Mast Chains
Forklift Mast Chains - Used in different functions, leaf chains are regulated by ANSI. They can be used for lift truck masts, as balancers between counterweight and heads in several machine devices, and for tension linkage and low-speed pulling. Leaf chains are occasionally likewise known as Balance Chains.
Features and Construction
Made of a simple pin construction and link plate, steel leaf chains is identified by a number which refers to the pitch and the lacing of the links. The chains have specific features like for example high tensile strength per section area, that allows the design of smaller devices. There are B- and A+ type chains in this particular series and both the AL6 and BL6 Series contain the same pitch as RS60. Lastly, these chains cannot be driven with sprockets.
Handling and Selection
Comparably, in roller chains, all of the link plates maintain higher fatigue resistance because of the compressive stress of press fits, whereas in leaf chains, just two outer plates are press fit. The tensile strength of leaf chains is high and the utmost allowable tension is low. If handling leaf chains it is important to confer with the manufacturer's guidebook so as to ensure the safety factor is outlined and use safety guards at all times. It is a good idea to exercise utmost care and use extra safety guards in functions where the consequences of chain failure are serious.
Higher tensile strength is a direct correlation to the utilization of more plates. For the reason that the use of more plates does not improve the most permissible tension directly, the number of plates could be restricted. The chains need frequent lubrication since the pins link directly on the plates, generating a very high bearing pressure. Utilizing a SAE 30 or 40 machine oil is normally advised for nearly all applications. If the chain is cycled more than 1000 times daily or if the chain speed is more than 30m per minute, it will wear very rapidly, even with constant lubrication. Hence, in either of these situations the use of RS Roller Chains will be more suitable.
AL type chains are only to be utilized under certain situations such as where there are no shock loads or when wear is not really a huge problem. Make sure that the number of cycles does not exceed 100 day by day. The BL-type would be better suited under various situations.
If a chain using a lower safety factor is selected then the stress load in parts would become higher. If chains are utilized with corrosive elements, then they can become fatigued and break quite easily. Performing regular maintenance is really vital if operating under these types of situations.
The kind of end link of the chain, whether it is an inner link or outer link, determines the shape of the clevis. Clevis connectors or also called Clevis pins are made by manufacturers but normally, the user supplies the clevis. A wrongly made clevis can decrease the working life of the chain. The strands should be finished to length by the manufacturer. Check the ANSI standard or get in touch with the producer.
